Speed up the re-analysis of large assemblies by constructing Superelements, and optionally, share Superelements with other manufacturers while concealing confidential design information.
Use "Modules" to combine and manage multiple components of a structure and form a complete assembly without the need to use additional connection elements or worry about the ID numbering schemes.Save time constructing assemblies that consists of welds or fasteners via specialized connector elements.Expedite meshing with Permanent Glue, enabling you to connect incongruent meshes that would traditionally require time consuming mesh transitions.MSC Nastran features a number of methods to join multiple components for system level structural analysis. Structural systems consist of numerous components, and must be analyzed as a whole. One structural member is rarely analyzed independently. Assess the behavior of advanced composites and fiber reinforced plastics with built in Progressive Failure Analysis and User Defined Services for Mean-field Homogenization coupling with DigimatĬustomer Testimonial MSC’s integrated solution for linear and nonlinear calculations facilitates reuse of models which saves a lot of time in pre- processing and enables us to standardize the data exchange formats for body models when collaborating with other departments or external suppliers.”.Perform fatigue analysis with embedded fatigue technologies and reduce the time usually associated with fatigue life determination.Use one platform to perform linear or nonlinear analysis for the following disciplines: static, dynamic (NVH & Acoustics included), thermal, and buckling, and reduce the dependency on multiple structural analysis programs from various vendors.MSC Nastran features multiple analysis disciplines, enabling customers with one structural analysis solution for a wide variety of engineering problems. To build up a comprehensive level of engineering analysis capability, multiple software solutions must be acquired, and users must be trained with each new tool. and MSC Software.Ĭommon structural analysis solutions are dedicated to one or a few analysis disciplines. The fatigue capability in MSC Nastran has been developed jointly by nCode International Ltd. A number of optimization algorithms are available, including MSCADS and IPOPT. Nonlinear FE problems may be solved with built-in implicit numerical techniques. MSC Nastran is based on sophisticated numerical methods, the most prominent being the Finite Element Method. Optimize the performance of existing designs or develop unique product differentiators, leading to industry advantages over competitors.Remedy structural issues that may occur during a product’s service, reducing downtime and costs.Virtually prototype early in the design process, saving costs traditionally associated with physical prototyping.Manufacturers leverage MSC Nastran’s unique multidisciplinary approach to structural analysis at various points in the product development process. MSC Nastran is also used to improve the economy and passenger comfort of structural designs. Engineers use MSC Nastran to ensure structural systems have the necessary strength, stiffness, and life to preclude failure (excess stresses, resonance, buckling, or detrimental deformations) that may compromise structural function and safety.
